Measuring range
External direct measuring range: 0-100mm
External comparison measuring range: 0-700mm
Internal direct measuring range: 2-100mm
Internal comparison measuring range: 10-450mm
External thread measuring range: till 200mm
Internal thread measuring range: M13 - M90
Work table
Vertical distance: 0-100mm/1mm
Horizontal distance: 0-25mm/ 0.01mm
Left-right swivel angle: ±4°
Up-down tilt angle: ±3°
| Resolution： | 0.0001mm/0.000001” |
|---|---|
| Measuring accuracy： | ±(0.5+L/200)um |
| Uncertainty of measurement： | (0.2+L/200)um |
| Measuring force： | 0、1.5、2.5N |
| The best temperature of measurement： | 20°C ± 1°C |
| Power： | 220V±10% |
| Instrument weight： | 100KG |
| Instrument dimension： | 1000x380x450mm |
