The Extech 382202 is a DC power supply with an adjustable output range of 0 V to 30 V and 0 A to 1 A. It has a dual backlit LCD display that shows current and voltage, as well as short circuit and overload safety. Uses 120 VAC ± 10%/60 Hz power supply. Banana plug outputs. Complete with a power cord.
| Line Current Regulation | <0.2% + 3mA |
|---|---|
| Line Voltage Regulation | <0.01% + 3mV |
| Load Current Regulation | <0.2% + 3mA |
| Load Voltage Regulation | <0.01% + 2mV |
| Output Current | 0 – 3.00A DC |
| Output Current Basic Accuracy | ±2% of reading |
| Output Voltage | 18.0V DC |
| Output Voltage Basic Accuracy | ±1.5% of reading |
| Ripple and Noise | <0.5mV/<3mA |
| Dimensions | 9.4 × 4.25 × 6" (240 × 108 × 154mm) |
| Power | 115V/230V; 50/60Hz |
| Warranty | 2 years |
| Weight | 6.6lbs. (3kg) |
